Machine top view
13. Vetilation opening.
14. Air assist pressure adjusting knob.
15. Air assist pressure display.
1. Status light.
2. Emergency switch.
Machine left side
12. Ventilation opening.
Machine back
16. Circuit breaker.
17. Compressed air filter.
18. Compressed air input plug.
19. Ethernet plug.
20. Power input plug.
21. Machine identification plate.
22. Exhaust output.
Machine chiller unit
23. Chiller display.
24. Chiller water inlet.
25. Water level indicator.
26. Ventilation fan.
27. Chiller water drain.
NOTE
In the case of a configuration with an air-cooled laser, the water chiller unit is not installed.
