Description of Product Chapter 1
23.06.15 Working Instructions WIDOS 4400 Page 9 of 44
1.5.1.4. Hydraulic aggregate
Power: 0,315 kW
Voltage: 230 V (r 10 %)
Current: 1,5 A
Frequency: 50 Hz
Phase shift: appr. 18°
Hydraulic fluid tank: appr. 1 L
System of protection: IP 54
Electro motor and pump:
Rotation speed: 1380 rpm
Max. working pressure of pump: appr. 120 bar
Working pressure: 100 bar
Volume velocity: 1,0 L/min
Weight: 23 kg
1.5.1.5.
Basic frame
Dimension (l x w x h): 600 x 320 x 300 (mm)
Reductions insert: Dimension upon request
Material of frame: Construction steel
Material of reduction inserts: Aluminium
Weight: 25 kg
of cylinder: 28 mm
of piston rod: 25 mm
Length of stroke of cylinder: 100 mm
max. force (F=P*A): 2500 N (at 100 bar)
Velocity of piston rod: 6,7 cm/s
1.5.1.6.
Reception box
Weight: appr. 4,0 kg
For article numbers and component parts see spare parts list
1.6. Equipment and accessories:
The following accessories are part of the first delivery:
1 Tool bag for 10 parts
1 Socket spanner size 24
1 Torx srew driver T10
1 each Allen key angulate size 3 / 5 / 6
1 each Allen key with T grip size 3 / 4
option Reduction inserts (large, extra large), roller brackets for the pipes, transformer
