45WIKA operating instructions, model CPG1200
EN
14603921.02 06/2023 EN/DE
In order to change the switch-off time, proceed as follows under “Menu” / “Measure
mode” / “Switch-off time”:
1. With the [LIGHT/▼] button or [ZERO/▲] button, select the desired language.
2. Confirm the setting by pressing the [MENU/◀▶] button.
⇒
The instrument moves back one menu level.
The input can be aborted with the [Home] button. The instrument exits the
menu and returns to the main display.
Press the [HOME] button in order to exit the menu.
7.4.4 Light off time
In the Light off time function, the time after which the backlighting switches off
automatically is specified.
If the setting is “Off”, the backlighting is continuous and does not switch off
automatically.
With the setting “30 s”, the backlighting of the display switches off automatically after
30 seconds. This time only applies after the last button press and is restarted if another
button is pressed in the meantime.
To change the Light off time function, proceed as follows under “Menu” / “Measure
mode” / “Light off time”:
1. With the [LIGHT/▼] button or [ZERO/▲] button, select the desired option.
2. Confirm the selection with the [MENU/◀▶] button.
⇒
The instrument moves back one menu level.
The input can be aborted with the [Home] button. The instrument exits the
menu, the selection is not adopted.
Press the [HOME] button in order to exit the menu.
7.4.5 User-defined unit
In addition to the standard units, there are one or two configurable custom units to
choose from. The user-defined units are defined in “Settings” / “User unit” by “Name
1”, “Factor 1” and “Name 2”, “Factor 2”.
The default designation is “UsUnit1” or “UsUnit2” and the factor “1.000”.
7. Operation via menu functions
