3. Signs, symbols and abbreviations
4. Function
The pressure prevailing within the application is transformed into a standardised electrical
signal through the deflection of the diaphragm, which acts on the sensor element with the
power supply fed to the digital gauge. This electric signal changes in proportion to the pres-
sure and is correspondingly displayed.
5. For your safety / 6. Packaging / 7. Starting, operation
Potential danger of life or of
severe injuries.
GB
Notice, important informa-
tion, malfunction.
The product complies with
the applicable European
directives.
Potential danger of life or
of severe injuries due to
catapulting parts.
Potential danger of burns
due to hot surfaces.
5. For your safety
Select the appropriate digital gauge with regard to scale range, performance
and specific measurement conditions prior to installing and starting the
instrument.
Observe the relevant national regulations (e.g.: EN 50178) and observe
the applicable standards and directives for special applications (e.g. with
dangerous media such as acetylene, flammable gases or liquids and toxic
gases or liquids and with refrigeration plants or compressors). If you do not
observe the appropriate regulations, serious injuries and/or damage
can occur!
Open pressure connections only after the system is without pressure!
Please make sure that the digital gauge is only used within the overload threshold limit all
the time!
Observe the ambient and working conditions outlined in section 7 „Technical data”.
Observe the technical data for the use of the digital gauge in connection with aggressive /
corrosive media and for the avoidance of mechanical hazards.
Ensure that the digital gauge is only operated in accordance with the provisions i.e. as
described in the following instructions.
Do not interfere with or change the digital gauge in any other way than described in
these operating instructions.
Remove the digital gauge from service and mark it to prevent it from being used again
accidentally, if it becomes damaged or unsafe for operation
Take precautions with regard to remaining media in removed digital gauge.
Remaining media in the pressure port may be hazardous or toxic!
Have repairs performed by the manufacturer only.
6. Packaging
Has everything been supplied?
Check the scope of supply:
Completely assembled digital gauge.
Inspect the digital gauge for possible damage during transportation. Should there be
any obvious damage, inform the transport company and WIKA without delay.
Keep the packaging, as it offers optimal protection during transportation (e.g.
changing installation location, shipment for repair).
Ensure that the pressure connection thread and the digital display will not be
damaged.
7. Starting, operation
Required tools: wrench (flats 27)
!
Warning
Caution
Warning
!
Warning
