9WIKA operating instructions pressure transmitter, model S-11
GB
14043046.01 06/2012 GB/D/F/E
3. Specications
3. Specications
3.1 Measuring ranges
Relative pressure
bar Measuring range 0 ... 0.1 0 ... 0.16 0 ... 0.25 0 ... 0.4 0 ... 0.6 0 ... 1 0 ... 1.6
Overpressure limit 1 1.5 2 2 4 5 10
Burst pressure 2 2 2.4 2.4 4.8 6 12
Measuring range 0 ... 2.5 0 ... 4 0 ... 6 0 ... 10 0 ... 16 0 ... 25 0 ... 40
Overpressure limit 10 17 35 35 80 50 80
Burst pressure 12 20.5 42 42 96 96 400
Measuring range 0 ... 60 0 ... 100 0 ... 160 0 ... 250 0 ... 400 0 ... 600
Overpressure limit 120 200 320 500 800 1,200
Burst pressure 550 600 600 600 1,600 1,600
Absolute pressure
bar Measuring range 0 ... 0.25 0 ... 0.4 0 ... 0.6 0 ... 1 0 ... 1.6 0 ... 2.5 0 ... 4
Overpressure limit 2 2 4 5 10 10 17
Burst pressure 2.4 2.4 4.8 6 12 12 20.5
Measuring range 0 ... 6 0 ... 10 0 ... 16
Overpressure limit 35 35 80
Burst pressure 42 42 96
Vacuum and +/- measuring range
bar Measuring range -0.1 ... 0 -0.16 ... 0 -0.25 ... 0 -0.4 ... 0 -0.6 ... 0 -1 ... 0 -1 ... +0.6
Overpressure limit 1 1.5 2 2 4 5 10
Burst pressure 2 2 2.4 2.4 4.8 6 12
Measuring range -1 ... +1.5 -1 ... +3 -1 ... +5 -1 ... +9 -1 ... +15 -1 ... +24
Overpressure limit 10 17 35 35 80 50
Burst pressure 12 20.5 42 42 96 96
