11. Accessories
14150915.07 11/2020 EN/DE/FR/ES
WIKA operating instructions, models TRxx and TCxx 29
11. Accessories
The seals can be ordered from WIKA, indicating the WIKA order number and/
or the designation (see table).
WIKA
order number
Designation Suitable for
threads
11349981 per DIN 7603 form C 14 x 18 x 2 -CuFA G ¼, M14 x 1.5
11349990 per DIN 7603 form C 18 x 22 x 2 -CuFA ʸʿÎʸƔʼƑ
11350008 per DIN 7603 form C 21 x 26 x 2 -CuFA G ½, M20 x 1.5
11350016 per DIN 7603 form C 27 x 32 x 2.5 -CuFA G ¾, M27 x 2
11367416 per DIN 7603 form C 20 x 24 x 2 -CuFA M20 x 1.5
1248278 per DIN 7603 D21.2 x D25.9 x 1.5 -Al G ½, M20 x 1.5
3153134
per DIN 7603 form C D14.2 x D17.9 x 2 -StFA
G ¼, M14 x 1.5
3361485
per DIN 7603 form C D33.3 x D38.9 x 2.5 -StFA
G 1
Legend:
CuFA = Copper, max. 45HB
a
; filled with asbestos-free sealing material
Al = Aluminium Al99; F11, 32 to 45 HB
b
StFA = Soft iron, 80 to 95 HB
a
; filled with asbestos-free sealing material
