AIR CONDITIONER · COOL 9 CONNECTED
without direct sunlight. Keep the other windows closed.
4. Slide and open the exhaust cover on the window panel and attach the
Rear clip. (Optional). See the attached yer for installing the window panel
correctly.
NOTE OF INSTALLING HEAT DISCHARGE PIPE
• In order to improve cooling efciency, the heat discharge pipe should be as
short as possible and at without curve to ensure smooth heat discharge.
• The length of the heat discharge pipe is less than 1m. It is recommended to
use it with shortest length.
• When installing, heat discharge pipe should be as at as possible. Don’t
prolong the pipe or connect it with other heat discharge pipe.
Correct
Correct
Correct
Wrong
