Fig. 4:
L1 L2 L3
Single pump
MA Twin pump
max. 20 A RK5
SL Twin pump
L1 L2 L3
SSMSBMDDGMPExt.offAUX
10V
/20mA
1
In1 GND
external supply
pressure sensor
min. 12 V DC / 10 mA
max. 250 V AC / 1 A
external value
10 V / 20 mA
external off (switch)
external off (switch)
pump cycling (button)
In2 GNDL H
+24V
23
SSMSBMDDGMPExt.offAUX
10V
/20mA
1
In1 GND
In2 GNDL H
+24V
23
