Wilo Wilo-Control SC-Booster Series User Manual

English
Installation and operating instructions Wilo-Control SC-Booster (SC, SC-FC, SCe) 41
5Product information
5.1 Type key
5.3 Scope of delivery
• Switchgear SC-Booster
•Wiring diagram
• Installation and operating instructions SC-Booster
• Installation and operating instructions frequency
converter (only for the SC-FC version)
• Test report acc. to EN 60204-1
5.4 Accessories
Accessories must be ordered separately:
Example:
SC
SCe
Smart Controller for fixed speed pumps
Smart Controller for electronic pumps
Booster Pressure boosting application
4x Number of pumps
3.0 Maximum nominal power P
2
[kW]
DOL
SD
Direct online (direct start)
Star-delta starting
FC With frequency converter
5.2 Technical data (standard versions)
Mains supply voltage [V]: 3~400/380 V (L1, L2, L3, PE)
Frequency [Hz]:
50/60 Hz
Control voltage [V]: 24 V DC; 230 V AC
Max. current consumption [A]:
See rating plate
Protection class: IP 54
Max. fuse protection on mains side [A]:
See wiring diagram
Ambient temperature [°C]:
0 to +40 °C
Electrical safety: Degree of contamination II
Option Description
BACnet MSTP
Connection to BACnet MSTP (RS485)
Modbus RTU Connection to ModBus RTU (RS485)
LON
Connection to LON
