5
Select a location to install the amplifi er
that is away from excessive heat,
direct sunlight, moisture and that has
proper ventilation.
Recommended installation locations
for in-vehicle are:
• Under the seat
• In the trunk
• Under the dash
Run the cable from the outside
antenna and attach it to the FME-Male
connector labeled “outside antenna” on
the amplifi er.
Installing a Wilson Amplifi er
Outside
Antenna
Amplifi er
DC Power
Supply
Cell Phone
Warning: Do not plug in the DC power
supply until the outside antenna and external
adapter cables are attached to the amplifi er.
!
In-Vehicle
To Next Page
