Installation Diagram
Outside Antenna
(Wide Band Directional
Antenna shown)
Inside Antenna
Power Supply
Inside Antenna
Preferred Method: Place the
Inside Antenna in the ceiling
facing down for the best
coverage.
Note: A Wilson Lightning Surge
Protector (859902) is recommended
for all building installations. Make sure
the protector is installed outside the
building at point of entry connected to
a suitable ground and in line between
the Outside Antenna and the Signal
Booster.
Surge Protector
Power Strip
To Next Page
