Part #104027 AIGR SBDT 007 - 07.11.07
Amplifi er Specifi cations
Dual-Band Wireless
800/1900 MHz Specifi cations
Model Number 271247
Connectors To onboard antenna: TNC Female To cradle antenna: F Female
Impedance Onboard antenna: 50 ohms Cradle antenna: 75 ohms
Dimensions 6.2 x 4.2 x 1.5 inch (15.7 x 10.7 x 3.8 cm)
Weight 0.64 lbs (0.29 kg)
Frequency 824-894 MHz / 1850-1990 MHz
1
Passband Gain (nominal)
800 MHz 55 dB Maximum
1900 MHz 55 dB Maximum
2
20 dB Bandwidth (nominal)
800 MHz 32 MHz
1900 MHz 74 MHz
Power output for single cell phone (uplink) 800 MHz 1900 MHz
CDMA 29.9 dBm 29.7 dBm
GSM 28.8 dBm 31.1 dBm
EDGE 30.8 dBm 31.1 dBm
AMPS 29.5 dBm
Power output for single received channel (downlink) 800 MHz 1900 MHz
CDMA 15.6 dBm 12.5 dBm
GSM 11.7 dBm 11.6 dBm
EDGE 12.4 dBm 9.5 dBm
AMPS 12.3 dBm
3
Power output for multiple received channels (uplink) Maximum Power
The maximum power is reduced
by the number of channels:
Number of
channels
800 MHz 1900 MHz
2 22.6 dBm 23.2 dBm
3 19.0 dBm 19.7 dBm
4 16.5 dBm 17.2 dBm
5 14.6 dBm 15.3 dBm
6 13.0 dBm 13.7 dBm
4
Power output for multiple received channels (downlink) Maximum Power
The maximum power is reduced
by the number of channels:
Number of
channels
800 MHz 1900 MHz
2 13.4 dBm 14.3 dBm
3 9.9 dBm 10.7 dBm
4 7.4 dBm 8.2 dBm
5 5.4 dBm 6.3 dBm
6 3.8 dBm 4.7 dBm
Noise Figure (typical) 3.5 dB nominal
Isolation (uplink/downlink) > 90 dB
Power Requirements 110-240 V AC, 50-60 Hz, 8 W
Notes:
1. Nominal gain is the maximum gain at any frequency in the passband.
2. Nominal bandwidth is the difference between two frequencies that are adjacent to the passband where the amplifi cation is 20 dB lower than the passband amplifi cation.
One of the frequencies is lower than the passband and the other is higher.
3. The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the rating would have
to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users. This power reduction is to be by means
of input power or gain reduction and not by an attenuator at the output of the device.
4. The maximum power for 2 or more simultaneous signals will be reduced by 6 dB every time the number of signals is doubled.
