Wilton 8014FW - Parts List: Band Saw Assembly (8020 FW Only)

40
Parts List: Band Saw Assembly (8020FW only)
(refer to breakdowns on pages 47-48)
Index No. Part No. Description Size Qty
1............... VBS2012-0500........ Gear Box........................................................... ................................... 1
2............... TS-0209091 ............ Socket Head Cap Screw.................................... 3/8-16 x 2”.................. 4
3............... TS-0720091 ............ Lock Washer ..................................................... 3/8”............................. 4
4............... TS-0680042 ............ Flat Washer....................................................... 3/8”............................. 4
5............... TS-0271091 ............ Socket Set Screw .............................................. 3/8-16 x 1”.................. 4
6............... 8020FW-16............. Oil Seal .............................................................
40x 30x7mm .......... 1
7............... 8020FW-17............. Oil Seal .............................................................
52x 30x7mm .......... 1
8............... VBS2012-0510........ Gear Box Cover................................................. ................................... 1
9............... TS-0050011 ............ Hex Cap Screw.................................................. 1/4-20 x 1/2” ............... 4
10............. TS-0720071 ............ Lock Washer ..................................................... 1/4”............................. 4
11............. TS-0680021 ............ Flat Washer....................................................... 1/4”............................. 4
12............. VBS2012-0520........ Gear.................................................................. ................................... 1
13............. VBS2012-0530........ Screw Nut.......................................................... ................................... 1
14............. VBS2012-0540........ Gear.................................................................. ................................... 1
15............. VBS2012-0550........ Gear Shaft......................................................... ................................... 1
16............. 8020FW-116 ........... Key.................................................................... 1/4 x 5/8” .................... 2
17............. VBS2012-0560........ Shaft Cover ....................................................... ................................... 1
18............. TS-0207121 ............ Socket Head Cap Screw.................................... 1/4-20 x 2½” ............... 3
19............. VBS2012-0570........ Gear.................................................................. ................................... 1
20............. VBS2012-0581........ Main Shaft......................................................... ................................... 1
21............. TS-1502071 ............ Socket Head Cap Screw.................................... 5 x 30mm ................... 2
22............. 8020FW-122 ........... Key.................................................................... 10 x 90mm ................. 1
23............. VBS2012-0591........ Main Shaft Cover............................................... ................................... 1
24............. TS-0207021 ............ Socket Head Cap Screw.................................... 1/4-20 x 1/2” ............... 3
25............. VBS2012-0600........ Speed Changing Shaft....................................... ................................... 1
26............. VBS2012-0610........ Speed Changing Arm ........................................ ................................... 1
27............. TS-0207041 ............ Socket Head Cap Screw.................................... 1/4-20 x 3/4” ............... 2
28............. TS-0561011 ............ Hex Nut ............................................................. 1/4-20......................... 2
29............. VBS2012-0611........ Shaft Stop ......................................................... ................................... 1
30............. TS-0207041 ............ Socket Head Cap Screw.................................... 1/4-20 x 3/4” ............... 1
31............. TS-0561011 ............ Hex Nut ............................................................. 1/4-20......................... 1
32............. TS-0270111 ............ Socket Set Screw .............................................. 5/16-18 x 1/2” ............. 1
33............. VBS2012-0612........ Spring................................................................ ................................... 1
34............. VBS2012-0620........ Slide Block ........................................................ ................................... 1
35............. VBS2012-0700........ Speed Changing Lever ...................................... ................................... 1
36............. VBS2012-0740........ Shaft Housing.................................................... ................................... 1
37............. TS-0209022 ............ Socket Head Cap Screw.................................... 3/16-24 x 5/8” ............. 3
38............. VBS2012-0790........ Speed Lever Ring.............................................. ................................... 1
39............. TS-0209031 ............ Socket Head Cap Screw.................................... 3/8-16 x 3/4” ............... 1
40............. 8020FW-140 ........... Pulley ................................................................ ................................... 1
41............. TS-0209051 ............ Socket Head Cap Screw.................................... 3/8-16 x 1”.................. 1
42............. 8020FW-142 ........... Oil Seal .............................................................
52x 25x7mm .......... 1
43............. VBS2012-9220........ Speed Lever Knob............................................. ................................... 1
44............. 8020FW-144 ........... V-Belt, 7072+7300............................................. ................................... 2
45............. 8020FW-145 ........... Ball Bearing....................................................... ................................... 3
46............. 8020FW-146 ........... Ball Bearing....................................................... ................................... 1
47............. 8020FW-147 ........... Ball Bearing....................................................... ................................... 1
48............. VBS2012-1010........ Work Table........................................................ ................................... 1
49............. 8020FW-149 ........... Table Support Frame......................................... ................................... 1
50............. TS-1533032 ............ Phillips Pan Head Machine Screw...................... 5 x 8mm ..................... 2
51............. TS-1551031 ............ Lock Washer ..................................................... 5mm........................... 2
52............. 8020FW-152 ........... Rivet.................................................................. 2mm........................... 4
53............. 8020FW-153 ........... Right Table Bracket ........................................... ................................... 1
54............. TS-0060091 ............ Hex Cap Screw.................................................. 3/8-16 x 2”.................. 2
55............. TS-0720091 ............ Lock Washer ..................................................... 3/8”............................. 2
