Ref Part.
No. Number Description Qty
1 5782511 Upper Arm, Frame 1
2 5782521 Bracket, Upper Wheel Sliding 1
3 5782531 Hinge, Upper Wheel Shaft 1
4 5782541 Pin, Pivot 2
5 5782551 Shaft, Upper Wheel 1
6 5782561 Pin, Roll (4x16) 1
7 5782571 Knob, Blade Track Adjustment 1
(M8x55)
8 5782581 Nut, Wing (M8x1.25) 1
9 5782591 Knob, Blade Tension Adjstmnt 1
10 5782611 Spring, Tension 1
11 5782621 Nut, Square 1
12 5782631 Guard, Upper Wheel (Inner) 1
13 5782641 Screw, Pan Head (M5x0l8x6) 3
14 5782651 Washer, Flat (M5x10) 2
15 5782661 Wheel, Upper 1
16 5782671 Bearing (6202Z) 2
17 5782681 Ring, Retaining (R-35) 2
18 5782691 Protector, Wheel 2
19 5782711 Nut, Hex (M12) 1
20 5782722 Blade, Saw, Metal Cutting 1
(92.5 x 0.025 x 14R)
5782732 Blade, Saw, Wood Cutting 1
(92.5 x 0.025 x 6H)
21 5782741 Bolt, Fixed 2
22 5782751 Catch 2
23 5782761 Screw, Pan Head (M5x0.8x12) 2
24 5782771 Bracket 2
25 5782781 Bolt, Hex Head (M8x1.25x16) 2
26 5782791 Lock, Male 4
27 5782811 Screw, Self Tapping (M4x0.7x8) 2
28 5782821 Stud 1
29 5782831 Guard, Blade 2
30 5782841 Retainer 2
31 5782851 Screw, Self Tapping (M3.5x12) 1
32 5782861 Hinge, Upper 12
33 5782871 Screw, Pan Head (M5x0.8x8) 12
34 5782881 Nut, Flange (M5x 0.8) 1
35 5782891 Guard, Upper Wheel (Outer) 1
36 5782911 Washer, Spring (M8) 2
37 5782921 Knob (M8x1.25) 1
38 5782931 Bracket, Switch 2
39 5782941 Screw, Self Tapping (M4x.7x10) 1
40 5782951 Switch 2
Ref Part.
No. Number Description Qty
41 5782961 Screw, Pan Head (M5x0.8x25) 2
42 5782971 Strain Relief (6W3-4R) 1
43 5782981 Cord, Power (110Volt, 1 phase) 1
5513899 Cord, Power (220 Volt, 3 phase)
44 5782991 Cord, Power (Switch to Motor - 1
110 Volt, 1 phase)
5513900 Cord, Power (Switch to Motor -
220 Volt, 3 phase)
45 5783011 Bushing, Power Cord 1
46 5783021 Clip, Wire 1
47 5783031 Screw, Hex Head (M6x1x55) 1
48 5783041 Base 1
49 5783051 Bolt, Hex Head (M16x2x55) 2
50 5783061 Washer, Flat (M16x40) 1
51 5783071 Nut, Hex (M16) 1
52 5783081 Hinge (Lower) 4
53 5783091 Screw, Flat Head (M5x10) 1
54 5783111 Guard, Lower Wheel 1
55 5783121 Chute, Dust 2
56 5783131 Screw, Pan Head (M6x1x8) 1
57 5783141 Bolt, Hex Head (Left Hand)
(M8x1.25x15) 1
58 5783151 Washer, Flat 1
59 5783161 Wheel, Lower 2
60 5783171 Bearing (6204Z) 1
61 5783181 Shaft, Lower Wheel 1
(Metal Cutting Saw)
5783191 Shaft, Lower Wheel 1
(Wood Cutting Saw)
62 5783211 Key (5x5x20) 4
63 5783221 Bolt, Hex Head (M8x1.25x40) 4
64 5783231 Washer, Flat (M8x18) 4
65 - - - - - - - - - - - - -
66 - - - - - - - - - - - - -
67 5783241 Pin, Dowel 1
68 5783251 Ball, Steel (8 mm) 1
69 5783261 Spring 1
70 5783271 Screw, Set (M10x1.5x10) 1
71 5783281 Knob (M10x1.4x30) 2
72 5783291 Screw, Pan Head (M6x1x12) 1
73 5783311 Bearing (6200ZZ) 1
74 5783321 Sleeve, Upper Spacing 7
75 5783331 Screw, Set (M6x1x10) 1
76 5783341 Post, Upper Support Bracket 1
77 5783351 Post, Guide 2
Ref Part.
No. Number Description Qty
78 5783361 Screw, Micro Adjustment 2
(M8x1x40)
79 5783371 Nut, Micro Adjustment 1
80 5783381 Screw, Hex Head (M6x1x10) 4
81 5783391 Blade Guide, Carbide 2
82 5783411 Bracket, Support 1
83 5783421 Guard, Upper Wheel Blade 1
84 5783431 Washer, Flat (M6x16) 2
85 5783441 Screw, Hex Head (M6x1x10) 1
86 5783451 Table 1
87 5783461 Pin, Roll (3x8) 1
88 5783471 Insert, Table 1
89 5783481 Pin, Table 2
90 5783491 Shoe, Trunnion Clamp 2
91 5783511 Bolt, Hex Head (M10x50) 2
92 5783521 Trunnion 1
93 5783531 Scale 6
94 5783541 Screw, Hex Head (M6x12) 1
95 5783551 Screw, Hex Head (M8x80) 2
96 5783561 Screw, Hex Head (M6x30) 2
97 5783571 Washer, Lock (M8) 1
98 5783581 Nut (M8x1.25) 1
99 5783591 Support, Bracket Trunnion 1
100 5783611 Pointer 2
101 5783621 Knob (M10x1.5) 2
102 5783631 Post, Lower Support Bracket 1
102 5783641 Block, Adjusting 1
104 5783651 Plate, Guide 2
105 5783661 Screw, Flat Head Socket 2
(M6x1x15)
106 5783671 Sleeve, Spacing 2
107 - - - - - - - - - - - - -
108 5783681 Bushing, Setting 4
109 5783691 Screw, Set (M5x0.8x5) 1
110 5783711 Bar, Adjusting 2
111 5783721 Handle 1
112 - - - - - - - - - - - - -
113 5783731 Bar, Adjusting 2
114 5783741 Washer, Spring (M8) 2
115 5783751 Nut, Flange (M8) 2
116 5783761 Washer 2
117 5783771 Spacer 1
Parts Listing – Saw Head – Models 8201, 8203, 8201VS, and 8203VS
