Wilton 8201 - Page 24

24
Ref Part.
No. Number Description Qty
1 5783831 Housing Gearbox 1
2 5629151 Bearing (6206ZZ) 1
3 9100441 Bearing (6200ZZ) 3
4 5783851 Bearing (6303ZZ) 1
5 5783861 Plug 2
6 5783871 Seal, Oil (30x7) 1
7 5783881 Seal, Oil (17x40x7) 1
8 5783891 Plug, Drain (1/8x28PT) 1
9 5783901 Plug (3/8x19PT) 1
10 5783911 Glass, Oil Level 1
11 5783921 Gear 1
12 5783931 Bearing (3206) 1
13 5783941 Ring, Internal Snap (R62) 1
14 5783951 Shaft (with gear) 1
Ref Part.
No. Number Description Qty
15 5783961 Key (5x5x18) 1
16 5783971 Bushing/Spacer 1
17 5783981 Gear 1
18 5783991 Shaft (with gear) 1
19 5784011 Key (5x5x40) 1
20 5513824 Pin, Parallel (5x20) 2
21 5784031 Key (7x7x20) 2
22 5784041 Ring, Retaining (S30) 3
23 5784051 Seal, Oil 1
24 5784061 Dog, Clutch 2
25 5784071 Pin, Roll (5x30) 2
26 5784081 Shaft, Clutch 1
27 5784091 Knob 1
28 5784111 Pulley 1
Ref Part.
No. Number Description Qty
29 5784121 Bushing 1
30 5513800 Cover, Bearing 1
31 5784141 Cover, Bearing 1
32 5784151 Cover, Bearing 1
33 5784161 Screw, Pan Head 9
(M5x0.8x8)
34 5784171 Screw, Pan Head 8
(M6x1x10)
35 5784181 Pulley, Gear Box 1
36 5784191 Screw, Set (M6x1x10) 2
37 5784211 V-Belt (A50) 1
38 5784221 V-Belt (A35) 1
39 5784231 Pin, Roll (4x16) 1
40 5518281 Oil, Gear Box 500cc (not 1
shown)
Parts Listing – Gearbox – Models 8201 and 8203
