Steps:
■ Use the drilling machine with 6mm drill to punch mounting holes in the place you want.
■ Insert the plastic expansion tube.
■ Fix bracket with screws.
■ Place the camera on to 1/4” tripod bolt and tighten hinge screw.
■ Adjust the camera to the direction you want and fix by counter screw.
■ Move to the position you need. Then, loose the hinge screw to adjust the final place. Tighten the two hinge
screw again at last to fix.
Connect to an External Monitor
The camera can be connected to an external monitor (e.g. TV). The steps are as following:
1. Connect the camera and the TV via AV cable.
2. Turns on the TV and change the mode to AV mode.
3. Power on the camera, switch to "TEST".
4. The camera screen is closed automatically after connecting successfully. The TV displays the photos and
videos of the camera.
Files Download
1. There are two ways to download the files from the camera to the computer:
2. Insert the Micro SD card into the card reader and connect to the computer.
3. Connect to a computer with a mini USB cable.
