Wimius H7 - Camera Components and Structure; Structure Overview

Trail Camera*1
Mini USB cable *1
Mounting belt*1
User manual *1
Metal bracket *1
Long screw of metal bracket *3
Plastic expansion tube *3
1. Infrared LEDs
2. Lens
3. Speaker
4. PIR Detector
5. 2.0” Display Screen
6. Mic
7. 1/4” Screw Hole
8. DC Power Input
9. OK Button
10. Down Button / Photo Mode
11. Up Button / Video Mode
12. Menu Button
13. Micro SD / TF Card Slot
14. Power Off
15. Test
16. ON Status
17. Mini USB Port
18. AV Port
1
2
3
4
5
6 7 8
9
10
11
12
13
14
15
16
17
18
Camera and Accessories
Structure
