Wimius T6 - Page 7

1. Schematic
Projector
Front
Back
① Lens (Focus Ring)
② Adjustable Foot
③ Air Intake
④ Remote receiver
⑤ Audio Output & Input
⑥ AV (video) Signal Input
⑦ Component Input
⑧ Power Switch
⑨ Power Input
⑩ Keystone Correction Ring
HDMI Interface
VGA Interface
USB Interface
1 32
4 5 6 7 8 10
11
12
9 13
P C- RG B I N
HD M I1
H DMI2
11
12
13
3
