2786400000 - Sensor2
12” Power Head
REF PART NO. PRV. NO. DESCRIPTION NOTES
100 86397640 50401BGWI POWER HEAD COVER WINDSOR S2-12
101 86397260 1013WI SUPPRESSOR KIT
102 86397570 50414WI CHASSIS 12"
103 86397580 50313sw BUMPER
104 86397390 05112WI SWITCH
105 86397480 50443UL SWITCHING UNIT
106 86397470 50308WI COVER FOR AIR CHANNEL
107 86140010 2856 CLAMP
108 86397590 50403kgER BRUSH ROLLER RELEASE
109 86397330 50356sw BEARING BLOCK R.H.
110 86397510 50367hg POSITION CAMS
111 86146220 2833 THRUST MEMBER
112 86397350 50352sw BRUSH STRIP COVER
113 86146230 2834 THRUST MEMBER
114 86397610 50404gsER FRONT BOTTOM PLATE
115 86137920 2849 AXLE CLAMP
116 86397600 50310gsER REAR BOTTOM PLATE
117 86400150 2868ZG ACCESS DOOR CPL.
118 86143850 2861 PILE ADJUSTMENT AXLE
119 86143920 5174sw PILE ADJUSTMENT WHEEL BLK
120 86397630 50415 BRUSH STRIP 12"
121 86397620 50470WI BRUSH ROLLER 12"
122 86005000 5110 BELT HTD-II, 219 3M
123 86397460 50332ER SPRING
124 86320320 2869sw RUBBING PLATE BLK
125 86397280 50348WI AXLE AND WHEEL
126 86397440 50330zg FOOT PEDAL
127 86397450 50331hg CATCH PEDAL
128 86397270 50334sw COVERING CAP
129 86397360 50306zg POWER SWITCH BUTTON
130 86397490 50371ER SWITCH ROD
131 86138230 5379 BELT 312 3M-HTDII-6 (RPL 5109)
132 86397520 50445ER SENSOR
133 86145460 5107-1 SUPPORT SPRING
134 86397400 50438hgER SUPPORT LEVER WITH SPRING
135 86397330 50355hg BEARING BLOCK L.H.
136 86397370 50465ER BRUSH MOTOR 120V
137 86139400 05117S CARBON BRUSH SET 100/120V
138 86143580 5117/1 MOTOR PULLEY
139 86397430 50441UL MOTOR COVER
140 86397420 50440ER SWIVEL SUPPORT R.H.
141 86397380 50436hgWI SWIVEL NECK CPL. 3 -WIRE
142 86397410 50439ER SWIVEL SUPPORT L.H.
143 86147030 0102ER SCREW, M3.9 X 13 DIN7981
144 86144850 0197ER SCREW, M4 X 12 HWH
145 86144780 01016ER SCREW, M4 X16-T20 SS
146 86397540 01010ER SCREW AM4X16
147 86397550 0104ER SCREW 3,9X25
148 86147170 0176ER SCREW, M4-.7 X 30 PHPNHMS ZN DIN7985
149 86397650 01042ER SCREW 4X10
150 86145250 2867 SPRING
