Windsor Chariot 2 CBPS20 - Page 47

4786356230 Chariot iGloss
Body Brace
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86273820 2 SCREW 1/4-20 X 1.25 HHCS SS
2 86010630 6 WASHER 1/4 ID X 5/8 OD SS
3 86340020 1 COVER, PANEL MNT BREAKER
4 86275120 4 SCR, 1/4-20 X.75 PPHMS PHIL
5 86340030 1 BREAKER, 100A CIRCUIT
6 86277500 2 SCR,1/4-20 X 5/8 CARR SS
7 86229770 1 BLOCK, SHUNT MOUNT
8 86005700 2 NUT 10-32 W/STAR WASHER PLTD
9 86271790 2 NUT, 6-32 HEX BRASS
10 86279600 4 WASHER, #6 FLAT BRASS
11 86253600 1 SHUNT, 50MV 70AMP
12 86276250 2 SCR, 6-32 X 3/8 SRHMS BR
13 86270770 2 NUT, 1/4-20 HEX
14 86271370 8 NUT, 1/4-20 FLANGE LOCK
15 86353270 1 BRACKET, CONTACTOR COVER
16 86006370 1 RELAY 36VDC 100 AMP HVY DUTY
17 86271130 2 NUT, 5/16-24 HEX JAM PLTD
18 86010670 2 WASHER, 5/16 FLAT SS
19 86353260 1 BRACKET, SOL TANK BRACE
20 86010680 2 WASHER 3/8 ID X 3/4 OD NYLON
