8386356230 Chariot iGloss
Pedal Platform
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86007110 1 SWITCH, 25A SPST 125-250V SNAP
2 86172980 9
SCR, KA50X10, PT OHS, WN1412,
PLTD
3 86264930 1 CABLE TIE, 3.5" UL/CS
4 86326150 1 BRKT, LINEAR POT
5 86326140 1 PIN, DOWEL .25 X 2.75, STEEL
6 86318010 1 PEDAL, HEEL
7 86318000 1 PEDAL, ACCELERATOR
8 86317990 1 PLATFORM, OPERATOR
9 86311560 1 POTENTIOMETER ASM, LINEAR
10 86254970 3 SPRING, COMP 18MM OD X 83 X 2
11 86173330 8 WASHER, M5, FLAT, ISO7093, SS
