Windsor Chariot 2 CBPS20 - Wiring Diagram 1

9386356230 Chariot iGloss
Wiring Diagram 1
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86354410 1 HARNESS, PANEL IGLOSS20
2 86356360 1
HARNESS, IGLOSS20 OPERATOR
PLATFORM
3 86354380 1 HARNESS, ROTARY SWITCH
4 86344450 HARNESS, MAIN ACTUATOR
5 86356350 1
HARNESS, IGLOSS20 MAIN POT AND
BRAKE
6 86356370 1 HARNESS, IGLOSS20 MAIN CHARGER
7 86356340 1 HARNESS, IGLOSS20 MAIN TRACTION
8 86354390 1 HARNESS, IGLOSS20 BRUSH
9 86354400 1 HARNESS, IGLOSS20 MAIN POWER
10 86333170 1 HARNESS, CS20 MAIN HORN
11 86354370 1 HARNESS, IGLOSS20 BAG PRESENT
12 86359290 1
HARNESS, iGLOSS20 SHUNT SENSE
JUMPER
13 86359300 1 HARNESS, iGLOSS20 SHUNT SENSE
14 86333140 HARNESS, CS20 MAIN VACUUM OPTIONAL
15 86359190 1
HARNESS, SHUNT JUMPER WIRE,
BRAIDED
16 86359200 1 HARNESS, SHUNT JUMPER WIRE
17 86362990 1 HARNESS, LOWER BRAKE
18 86365410 1 HARNESS, LOWER TRACTION
