Windsor Chariot 2 CBPS20 - Wiring Diagram 3

9786356230 Chariot iGloss
Wiring Diagram 3
REF DESCRIPTION
A1 DRIVE CONTROL
A2 RELAY BOARD
A3 PROCESSOR
F1 CIRCUIT BREAKER-DRIVE CONTROL
F2 CIRCUIT BREAKER-VACUUM MOTOR - OPTIONAL
F3 CIRCUIT BREAKER-BRUSH
G1-G3 BATTERY 12V
H1 SIGNAL LAMPS REVERSE DIRECTION
H2 SIGNAL LAMPS DIRECTION FORWARD
H3 HORN
H4 LED-BATT.
H5 LED
H6 LED
K1 RELAYS-REVERSE DIRECTION
K2 RELAYS DIRECTION FORWARD
K3 RELAYS BRUSH MOTOR
K4 RELAY VACUUM MOTOR - OPTIONAL
K5 RELAYS ACTUATOR
K6 RELAYS MAIN
M1 BRUSH MOTOR
M2 VACUUM MOTOR - OPTIONAL
M3 TRACTION MOTOR
M4 LINEAR ACTUATOR MOTOR BRUSH / SQUEEGEE
S0 EMERGENCY SWITCH
S1 KEYSWITCH
S2 MICROSWITCH-PLATFORM
S3 BUTTON REVERSE FORWARD
S4 HORN BUTTON
S5 MICROSWITCH-COVER
S8 PROGRAM SWITCH
S11 CHARGER
S12 BAG PRESENT
R1 SHUNT
P1 HOURS METER
V1-V2-V3-V4-V5-V6-V7-
V8-V9-V10-V11-V12
DIODE
V-UP & V-DOWN DIODE-MOTOR M4
X3 TERMINAL BLOCK
X12 TERMINAL BLOCK
** X6-X7-X8-X11 DEUTSCH CONNECTOR
* X9-X10-X13 PACKARD CONNECTOR
X14 FASTON TERMINAL
X15 RING TERMINAL
Y1 BRAKE
