Windsor Chariot 2 CBPS20 - Page 49

4986356230 Chariot iGloss
Body Lower
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86273980 2 SCREW 10-32 X 3/4 PPHMS SS
2 86010650 2 SP WASHER #10 X 9/16 OD
3 86354990 2 CLAMP, .75 DIA, FLEX LOOP, NYLON
4 86010670 2 WASHER 5/16 FLAT SS
5 86279130 4 WASHER 5/16 SPLIT LOCK PLTD
6 86276780 2 SCR, 5/16-18 X 3/4 HHCS SS
7 86354570 2 BRACKET, SPRING, UPPER
8 86353220 2 SPRING, EXTENSION
9 86353720 2 BRACKET, SPRING, LOWER
10A 86353200 1 MAIN BODY, LB,OBC, TRIM
10B 86358530 1 MAIN BODY, LB, NO OBC, TRIM
SHELF CHARGER
MODELS ONLY,
1.002-033.0
1.002-035.0
11 86353280 1 HOSE 1.5" X 49", 4:1 STRETCH
12 86264940 3 CABLE TIE 11.38" UL/CSA
