Windsor Chariot 2 CBPS20 - Page 63

6386356230 Chariot iGloss
Control Panel
* QUANTITY OF 1 FOR PASSIVE MODEL
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86275260 4 SCR, 4-40 X 1/2 PPHMS
2 86326390 2 CONN, 8MM PITCH, 10 POSN
3 86352490 1 PANEL, CONTROL iGLOSS 20
4 86255910 2 STANDOFF, 1/4-20 X 1.0 HEX INS
5 86006850 1 SCR, 1/4-20 X 1.25 SSSCU
6 86005710 4 NUT, 1/4-20 HEX W/STAR
7 86279450 3 WASHER, #6 FLAT SAE PLTD
8 86354860 4 STANDOFF, 6-32 X 1.25L, NYL
9 86356320 1 CONTROLLER, iGLOSS 20
10 86275550 2 SCREW 6-32 X 1.25
11 86279020 1 WASHER #6 LOCK EXT STAR SS
12 86336110 1 RELAY, SPST-NO
13 86336100 3 CLIP, RELAY
14 86313900 3 RELAY, 5A, 24V, 4PDT
15 86255900 4 STANDOFF, 6-32 X 5/8 HEX NYL
16 86347250 1 PCBA, RELAY OMRON II
17 86005810 2* NUT, 1/4-20 HEX NYLOCK SS ACTIVE MODEL ONLY
18 86010630 2* WASHER, 1/4 X 5/8 FLAT SS ACTIVE MODEL ONLY
19 86251360 1 RELAY, 36VDC, 100A ACTIVE MODEL ONLY
20 86337210 5 SPACER, .14ID X .25OD X .38, NYL
21 86354430 1 PCB, ROTARY SWITCH
22 86274570 4 SCR, 4-40 X 1/4 PPHMS
