Windsor Chariot 2 CBPS20 - Page 65

6586356230 Chariot iGloss
Control Panel
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86332510 1 BOOT, SEAL PUSH BUTTON 11MM ACTIVE MODEL ONLY
2 86001260 1 BOOT, CB 3/8-32 UNS
3 86348640 2 LED, BAG FULL INDICATOR
4 86348960 1 LED, BATTERY INDICATOR
5 53217380 1 KNOB, SELECTION
6 63130140 1 SPRING ELEMENT
7 86295200 1 ASM, BUTTON, BLACK, W/BEZEL
8 86313950 1 SWITCH, SPDT 3 POSN MOM, ARROW
9 86292590 1 SWITCH, E-STOP AKW CHARIOT
10 86292780 1 SWITCH,MICRO
11 86007170 1 SWITCH, KEY 2 POSITION
12 86358430 2 SCR, M4X12 FHMS, ISO7046 SS NP
13 86255900 4 STANDOFF, 6-32 X 5/8 HEX NYL
14 86354870 1 SWITCH, ROTARY
15 86354560 1 BEZEL, ROTARY SWITCH
16 86315470 1 METER, HOUR, LCD
17 86354810 1 GASKET, SCE42B W/5008B PSA
18 86353680 1 BREAKER, 1.5A, CARLING MAGNETIC
19 86316160 1 BREAKER, 18A, 250VAC, 32VDC ACTIVE MODEL ONLY
20 86329570 4 SCR, PAN HD #10-32 X 1.0 TORX, SS NP
21 86358440 2 O-RING, 4MM ID, 1.5MM THK, BUNA-N
