7386356230 Chariot iGloss
Drive-Chain
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86330720 1 CHAIN TENSIONER
2 86329350 1 NUT, 1/4-20 X 7/8 HEX COUPLING SS
3 86328050 2 WASHER, SHOULDER.48ID X 1.25OD
4 86005810 3 NUT, 1/4-20 HEX NYLOCK SS
5 86273100 3 SCR, 1/4-20X2-1/4 HXHD CAP
6 86322060 1 COLLAR, 12MM ID
7 86322050 1 SPROCKET, STEERING, 14T
8 86322040 1 PLATE, CHAIN RING
9 86322030 3 SPACER
10 86270830 7 NUT, 5/16-18 HEX NYLOCK SS
11 86319740 1 PLATE, UPPER CLAMP
12 86319680 1 PLATE, LOWER CLAMP
13 86319610 1 BRACKET, BEARING CLAMP
14 86319600 1 BRACKET, DRIVE MOUNT
15 86319590 1 SHAFT, STEERING SPROCKET
16 86319560 1 CHAIN, ISO O8B, 12.7MM PITCH
17 86014440 1 BEARING, DRIVE
18 86224270 1 SLEEVE, CHAIN TENSIONER
19 86259430 1 WASHER, 12.5 ID X 26 OD X 2T FLAT
20 86279510 1 WASHER, 3/8 X 1 FLAT NP
21 86010780 1 WASHER, 1/4 SPLIT
22 86010670 4 WASHER, 5/16 X 3/4 SS
23 86010630 7 WASHER, 1/4 X 5/8 FLAT SS
24 86005710 3 NUT, 1/4-20 HEX W/STAR
25 86271930 1 NUT, 3/8-16 HEX NYLOCK SS
26 86276070 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
27 86275190 1 SCR, 3/8-16 X 1.25 HHCS SS
28 86274150 4 SCR, 1/4-20 X 1.75 HHCS
29 86232780 - CHAIN MASTERLINK 12.7MM
30 86368600 1 WASHER, 2.5 OD X 1.25 ID X .125 THK, DELRIN
31 86279420 2 WASHER .75IDX1.25ODX.125THK NY
32 86271370 2 NUT, 1/4-20 SERFLG STL ZNPLT
