Windsor Chariot 2 CBPS20 - Page 75

7586356230 Chariot iGloss
Drive-Lower
For installation of 8.636-401.0 with brake harness and lower harness, order kit 8.636-900.0
* SEE SERIAL NUMBER PAGE
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86326710 1 KEY, 5 X 5 X 16
2 86321670 2 WASHER, WHEEL SPACER
3 86319810 1 AXLE, DRIVE WHEEL
4 86319670 6 SLEEVE, BEARING
5 86364010 1 MOTOR, TRACTION (4*)
- 86331990 - BRUSH SET, SMALL RIDER DRIVE MTR NOT SHOWN
- 98408960 - BRAKE REPLACEMENT SMALL STAND ON NOT SHOWN
6 86319650 2 SPROCKET, DRIVE, 14T
7 86319640 1 CHAIN, ISO O8B, 12.7MM PITCH
8 86319620 1 FRAME, LOWER DRIVE
9 86316890 1 WHEEL, PU 200MM X 50MM
10 86279630 3 WASHER, .344IDX1.130ODX.09T PLT
11 86358800 5 WASHER, M6 CONICAL
12 86010670 4 WASHER, 5/16 X 3/4 SS
13 86008610 4 FLANGE, BEARING PRESSED STEEL
14 86272550 3 PIN, CLEVIS, 5/16 X 1.00 PLTD
15 86276070 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
16 86358820 3 SCREW, M6-1.0 X 16 HCS 10.9Z
17 86136640 3 SCR, M8 X 20 HHMS
18 86358810 2 SCREW, M6 - 1.0 X 30 HCS 10.9Z
19 86270830 4 NUT, 5/16-18 HEX NYLOCK SS
20 86219640 1 KEY, 1/4 SQ. X 1.5
21 86332380 3 ROLLER, 1.1 OD
22 86001030 2 BEARING, BALL 3/4 BORE SPHERED
23 86008660 3 COTTER 5/16" RING
24 86002830 1 CABLE TIE .375 X 24.7
25 86232780 - CHAIN MASTER LINK 12.7MM NOT SHOWN
26 86362040 2 TAPE CLOSED CELL 1/8 X 3/4 X 2 1/2 PSA (1*)
27 86264920 2 CABLE TIE, 7" UL/CSA (1*)
28 86362140 3 SCREW, M6 X 12MM, HEX FLANGE, PLTD (3*)
29 86348490 1 NUT, WELD 5/16-18 X .38, TAB BASE, STL (3*)
30 86362130 1 SCREW, 5/16 X 1.50, SHCS, SS, FT (3*)
31 86362150 2 SCREW, M6 X 30MM, HEX FLANGE, PLTD (3*)
32 86288500 4 NUT, M4-.7 HEX STL CL8 ZNPLT
33 86134850 2 WASHER,SPRNG LK,M4,DIN127B,SST
34 86372230 2 WASHER, EXT TOOTH STAR
