Windsor Chariot 2 CBPS20 - Page 89

8986356230 Chariot iGloss
Vacuum-Optional
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86273920 3 SCREW 1/4-20 X 1.75 PPHMS SS
2 86010630 3 WASHER 1/4 ID X 5/8 OD SS
3 86353290 1 BRKT, VAC MOTOR
4 86312920 1 GASKET, VAC MOTOR
5 86012210 1 VAC MOTOR, 36VDC 2ST TD
6 86264940 1 CABLE TIE, 11.38" UL/CSA
7 86327500 3 MOUNT, VIBRATION
8 86002400 1 CLAMP, 2.0" WORM GEAR X .312W
9 86320330 1 HOSE ASM, 1.5 BLK VAC X12
10 86356150 1 HOSE, 1.5" X 7.75", 4:1 STRETCH
11 86291220 2 SCR, KA40X16,PT FLAT,WN1413,SS
12 86355910 1 CLIP, 1-3/4", PLASTIC
13 86143330 1 MOTOR FILTER U19836
14 86354650 1 FRAME, FILTER
15 86277640 2 SCREW 1/4-20 X 3/4 PTHMS SS
