Windsor Chariot 2 CBPS20 - Page 91

9186356230 Chariot iGloss
Wiring-Battery
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86329720 2 BATT, CBL, ASM, JUMPER
2 86356120 1 CABLE, ASM, BATTERY
3A 86228400 3 BATTERY, 12V, 130AH
3B 86328630 3 BATTERY, 12V 114A/H AGM NOT SHOWN
3C 86283410 3 BATTERY, 12V, 225AH (J185H-AC) NOT SHOWN
3D 86228430 3 BATTERY, 12V AGM 234AH NOT SHOWN
4 86008300 1 TRAY, BATTERY LINER
REQD. WITH 86283410 &
86228430
5 86359550 1 TAPE, 1/16" T X 6.0" SQ. 2 SIDE ADH
