WIRING-BATTERIES
86037880 CHARIOT EXTRACTOR 10/20/08
5-50
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1A 86260200 80872 2 WIRE, 4X14.5BK 5/16RINGX5/16RING
1B 86002510 23125 2 WIRE, 4X15 BCLAMPXBCLAMP
2 86008920 80889 6 BOOT, RUBBER TERM. ISOLATOR
3 86271910 57295 6 NUT, 5/16-18 FLEXLOCK
4 86010670 87029 6 WASHER, 5/16 FLAT SS
5 86264960 27915 2 CABLE TIE, .375 X 43”
6A 86260610 880836 1 WIRE, 4X25RD CTERM X 3/8RING
6B 86002570 23190 1 WIRE, 4X27 RD BCLAMP X CTERM
7A 86260230 80876 1 WIRE, 4X30 BK CTERM X 3/8RING
7B 86002580 23191 1 WIRE, 4X27 BK BCLAMP X CTERM
8 86008760 80682 1 CONN, 175 DCA GRY W/O TERMS
9 86229700 08071 3 BLOCK, 3.0 X 1.5 X 1.5
10 86008300 78242 1 TRAY, BATTERY LINER
11 86008410 78568 1 TRAY, BATTERY
12 86272810 67132 1 RING, 1/2 EXT. SNAP H-D
13 86092910 51396 1 LATCH ROD, BATTERY TRAY
14 86254990 730313 1 SPRING, COMP, 63ODX3.5LX.074W
15 86278150 70117 8 SHOULDER BOLT, 5/16 OD X 1.0 L
16 86259910 89265 8 WHEEL, BATTERY TRAY
17 86088790 78571 2 TRAY, STANDARD STOP
18 86276070 70593 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
19 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
20A 86228430 10023 3 BATTERY, 12V, 205AH
20B 86283410 10030 3 BATTERY, 12V, 225AH
21 86284090 02456 1 CHARGER, 36V, 20A, 115V, C175
NOT SHOWN
22 86005810 57245 8 NUT, 1/4-20 HEX NYLOCK SS
23 86233360 28038 1 CLAMP, CABLE KIT SY945
24 86273980 70066 1 SCREW, 10-32 X 3/4 PPHMS SS
25 86010650 87018 1 WASHER, 10 X 9/16 OD
26 86270890 57034 1 NUT, ACORN 10-32
To Next Page
