MAINTENANCE-SOLUTION STRAINER & PUMP
86037880 CHARIOT EXTRACTOR 01/14/08
4-14
3
1
5
4
2
6
1. Solution Strainer – Coarse
2. Solution Strainer – Fine
3. Pump
4. Solenoid Valve
5. Jets
6. Shut-off Valve
