TECHNICAL SPECIFICATIONS
86037880 CHARIOT EXTRACTOR 01/26/12
3-1
ITEM DIMENSION/CAPACITY
Nominal Power 2952 W
Rated Voltage 36 Volts DC
Rated Amperage 82 amps
Batteries 3 X12 Volt 195-215 AH @ 20 hr. rate
Battery Compartment Dimensions 21 in. x 16 in. x 17 in. tall
(533mm x 406mm x 432mm)
Propelling Motor .75 HP (560 W)
Mass (GVW) 1400 lbs (635 kg)
Weight Empty Without Batteries 821 lbs (372 kg)
Solution Control 1.3 GPM pump metered flow with automatic shut-off in neutral
Spray Pump Pressure 100 psi
Solution Capacity 25 gal (95Liter)
Spray Jets 2
Recovery Capacity 25 gal (95 Liter)
Vacuum Motors 2 x .75 HP (560W)
Maximum Flow Rate of Vacuum Motor 77.0 cfm (36.4 Liters per second)
Maximum Suction Of Vacuum Motor 81.8 inches of water (20.3 kPa)
Scrub Brush Diameter 6 inch (152 mm)
Scrub Brush Motors 2 x .75 HP (560W)
Scrub Brush Pressure Floating
Scrub Brush Speed 800 rpm
Tires 10 in. (254mm) Solid Gray non-marking
Extracting Speed 1 60 feet per minute (18 m/min)
Extracting Speed 2 132 feet per minute, 1.5 mph (40 m/min, 2.4 Km/hr)
Maximum (Transport) Speed 3.5 miles/hour (5.6 Km/hour)
Frame Construction Powder coated steel
Brake Electrical parking brake, sets automatically whenever operator
steps off platform or engages emergency stop.
Minimum Aisle U-Turn Width 56 in. (1425 mm)
Maximum Rated Climb And Descent Angle 7.5 degrees
