TECHNICAL SPECIFICATIONS
86037880 CHARIOT EXTRACTOR 01/16/07
3-2
ITEM MEASURE
Height 50.6 inches (1285 mm)
Length 52.5 inches (1330 mm)
Width 26.5 inches (670 mm)
Width of scrub path 23 inches (585 mm)
The weighted root mean square acceleration at the
operator’s arms was measured to be below 2.5m/s
2
.
This was a tri-axial, third-octave-band measurement
made during normal operation on a composite tile
floor. The measurement and related calculations were
made in accordance with ANSI S3.34-1986.
SPECIAL NOTES:
The sound pressure level at the operator’s ear was
measured to be 70 dBA. This was a nearfield, broadband
measurement taken in a typical industrial environment on
a tile floor. This appliance contains no possible source of
impact noise. The instantaneous sound pressure level is
below 63 Pa.
LENGTH
WIDTH
