CONTROL PANEL - UPPER
86037880 CHARIOT EXTRACTOR 01/16/07
5-4
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86002010 14942 2 BOOT, 3/8 CIRCUIT BREAKER
2 86008900 80845 5 BOOT, SEAL-PUSH BUTTON 7/16-28
3 86007130 72128 1 SWITCH, DPDT 2-POSITION ROCKER
4 86007140 72130 1 SWITCH, SPST 2-POSITION ROCKER
5 86007180 72160 1 SWITCH, EMERGENCY STOP
6 86007190 72161 1 SWITCH KEY DPST
7 86246930 54144 1
METER, 36V BATTERY CHARGE
LEVEL
8 86257140 72196 1 SWITCH ASM, SEALED PB RND BRN
9 86257280 81371 1 SWITCH, PUSH BUTTON
10 86257110 72189 1 SWITCH, 4P3T FIXED POS ROCKER
11 86005530 54154 1 METER, 12-48 VDC LED HOUR
12 86251410 67506 1 RELAY, 15A 36V MINI
13 86255900 73538 8 STANDOFF, 6-32 X 5/8 HEX NYL
14 86273990 70067 10 SCR, 6-32 X 3/8 PPHMS
15 86279300 87134 10 WASHER, #6 LOCK
16 86002000 14717 2 BREAKER, 3 AMP
17 86001920 14607 2 BREAKER, 25A 50 VDC CIRCUIT
18 86001910 14606 3 BREAKER, 30A 50VDC CIRCUIT
19 86229770 140805 1 BLOCK, SHUNT MOUNT
