CONTROL PANEL-LOWER
86037880 CHARIOT EXTRACTOR 09/21/07
5-6
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86223740 70872 6 SCR, 1/4-20 X .59 PPHMS SS C
2 86273820 70019 2 SCR, 1/4-20 X 1.25 HHCS
3 86277480 70850 3 SCR, 5/16-18 X 1/2 PTHMS SS
4 86070720 140728 1 BRKT, BATT CONN, BASIC
5 86008760 80682 1 CONN, 175 DCA GRY W/O TERMS
6 86005810 57245 8 NUT, 1/4-20 HEX NYLOCK SS
7 86075310 61039 1 CONTROL PANEL, EXTRACTOR
8 86271840 57285 3 NUT, 5/16-18 HEX NYLOCK THIN SS
9 86006370 67315 3 RELAY, 36VDC 100AMP HVY DUTY
10 86010670 87029 6 WASHER, 5/16 FLAT SS
11 86279130 87083 6 WASHER, 5/16 SPLIT LOCK PLTD
12 86271120 57125 6 NUT, 5/16-18 BRASS
13 86005700 57104 8 NUT, 10-32 W/STAR WASHER PLTD
14 86027740 27911 1 CONTROLLER, GEAR DRIVE BASIC
To Next Page
