Windsor chariot iExtract CE24 - Page 61

FRAME-LOWER
86037880 CHARIOT EXTRACTOR 01/16/07
5-12
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86070750 140731 1 BRKT, LINKAGE, LEFT
2 86071130 140812 1 BRKT, TIP BRACE, LEFT, REAR
3 86070760 140733 1 BRKT, BRACE, LEFT FRONT
4 86276070 70593 16 SCR, 5/16-18 X 3/4 CARRIAGE SS
5 86092500 34428 1 FRAME, MAIN
6 86197040 57264 4 NUT, 5/16-18 HEX ACORN PLTD
7 86279130 87083 4 WASHER, 5/16 SPLIT LICK PLTD
8 86270830 57023 20 NUT, 5/16-18 HEX NYLOCK SS
9 86071120 140811 1 BRKT, TIP BRACE, RIGHT, REAR
10 86071430 140863 1 BRKT, BRACE, RGT FRONT
11 86070740 140730 1 BRKT, LINKAGE, RIGHT
12 86079320 620101 2 PLATE, PAD RETAINER
13 86064300 140790 2 PAD, TIPPING BAR
14 86010670 87029 4 WASHER, 5/16 FLAT SS
15 86091420 05251 1 AXLE, REAR WELDMENT
16 86088760 75458 1 TRAY, SLIDE, LEFT
17 86088750 75457 1 TRAY, SLIDE, RIGHT
18 86079290 620097 2 PLATE, REAR COVER ADJ.
19 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
20 86271870 57290 4 NUT, 1/4-20 HEX NYLOCK THIN SS
21 86276950 70772 4 SCR, 1/4-20 X 3/4 CARRIAGE SS
