Windsor chariot iExtract CE24 User Manual

FRAME-UPPER
86037880 CHARIOT EXTRACTOR 01/16/07
5-14
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86091610 140129 1 BRKT, HORIZ ELECT, EXTRACTOR
2 86270830 57023 8 NUT, 5/16-18 HEX NYLOCK SS
3 86010670 87029 5 WASHER, 5/16 FLAT SS
4 86276070 70593 7 SCR, 5/16 X 3/4 CARRIAGE SS
5 86083080 66437 1 PLATE, VERT BEARING SUPPORT
6 86277460 70847 1 SCR, 5/16-18 X 5/8 BSHCS SS
7 86073500 270090 1 BRKT, SIDE CHANNEL L
