PEDAL PLATFORM-From Serial Number (11*)
86037880 CHARIOT EXTRACTOR 03/31/10
5-15B
NOTE: Complete platform assembly is available, Part No. 86028310.
**CALL MANUFACTURER FOR SERIAL NUMBER
*SEE SERIAL NUMBER PAGE
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL
NO.
FROM
NOTES
1 86233170 20054 2 CLAMP, 3/8 NYLON UL/CSA
2 86264920 27049 1 CABLE TIE, .19 X 7 UL/CSA
3 86222510 34430 1 PEDAL, THROTTLE
4 86221850 34433 1 LINK, THROTTLE
5 86136310 57086 1 NUT, M5 HEX
6 86312820 - 1 BRACKET, POT, SPEED
7 86288720 57277 1 NUT, M6 NYLOCK PLATED
8 86272040 57503 2 NUT, M3.5 X 2.8 HEX
9 86223260 66085 1 PLUNGER, PLATFORM SWITCH
10 86223580 67502 1 ROD, PIVOT, 8.5MM X 77
11 86274340 70179 7 SCR, M6 X 16 PH
12 86278060 70759 2 SET SCR, M4 X 4MM NP
13 86277360 70833 1 SCR, M6 X 10 PH
14 86277370 70834 1 SCR, M5 X 30 SHCS
15 86277380 70835 4 SCR, M4.8 X 16 PHTF
16 86277390 70836 2 SCR, M3.5 X 38 PH
17 86312770 - 1 PLATFORM
18 86007110 72123 1 SWITCH, 25A SPST 125-250V SNAP
19 86224750 73993 1 SPRING, COMP, .48OD X .91L
20 86279140 87085 6 WASHER,M6 SPLIT LOCK DIN127B
21 86279720 87248 2 WASHER, M4 INT STAR
22 86279730 87249 4 WASHER, M5 INT STAR
23 86224360 730325 1 SPACER 12.7MMOD X 2.78W X 6L
24 86224350 730305 1 SPACER, 8MM X 16LG
25 86333280 - 2 BUSHING, 8MM X 10 LG SS
26 86222780 620047 1 PLATE, PIVOT
27 86222810 620050 1 PLATE, COVER
28 86254970 730304 1 SPRING, COMP 18MM OD X 83 X 2
29 86137300 87084 2 WASHER, M5 SPLIT LOCK PLTD
30 86250280 66135 1 POTENTIOMETER 5K OHMS
To Next Page
