SCRUB DECK MOTORS
86037880 CHARIOT EXTRACTOR 01/16/07
5-24
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86277880 70855 8 SCR, M8-1.25 X 35 LG SHCS SS
2 86222330 57504 2 NUT, M8 -1.25 HEX JAM SS
3 86279790 87489 6 WASHER, M8 (THICK) FLAT SS
4 86137310 87098 6 WASHER, M8 SPLIT LOCK
5 86217710 29268 2 DOOR, CYLINDRICAL BRUSH
6 86219290 34418 2 HOUSING, SCRUB PLUS DRIVE
7 86219450 41488 2 HUB, TRI-STAR BRUSH IDLER
8 86223520 67598 2 RING, 28 MM INT SNAP PHOSPHATE
9 86228960 09149 4 BEARING, 15 X 28 X 7W SS BALL
10 86279770 87487 4 WASHER, M6 LARGE OD FLAT SS
11 86279140 87085 4 WASHER, M6 SPLIT LOCK DIN127B
12 86277870 70854 4 SCR, M6-1.0 X 20 LG BHSCS SS
13 86219440 41487 2 HUB, TRI-STAR BRUSH DRIVE
14 86279780 87488 2 WASHER, M16 SMALL OD FLAT SS
15 86004820 48041 2 KEY, 3/16 SQ X 7/8 CRS
To Next Page
