SCRUB DECK LIFT ACTUATOR
86037880 CHARIOT EXTRACTOR 09/14/07
5-26
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86011950 - 1 ACTUATOR, 36VDC, 3.5 IN STRK
*(1)
WAS 05250
2 86248980 81438 3 PIN, CLEVIS 3/8 X 1.75 PLTD
3 86006910 70443 2 SCR, 1/4-20 X 5/8 SHCS
4 86090330 87258 2 WASHER, .804ID X 1.25OD X .179
5 86278400 730351 1 SPRING, COMP., 1.10 OD X 2.25 L X 148
6 86066920 140852 1 BAR, COMP. SPRING RETAINER
7 86273820 70019 1 SCR, 1/4-20 X 1.25 HHCS SS
8 86070190 140581 2 BRKT, SCRUB DECK GUIDE 36V
9 86276760 70724 2 SCR, 5/16-18 X 1.25 BSHCS SS
10 86010670 87029 6 WASHER, 5/16 FLAT SS
11 86228840 09124 2 BEARING, FLANGED .314 ID X .502 OD
12 86259420 87232 4 WASHER, THRUST .51ID X 1OD
13 86091840 140850 1 BRKT, ACTUATOR SLIDER
14 86005810 57245 5 NUT, 1/4-20 HEX NYLOCK SS
15 86231360 14744 2 BUSH, BRZ FLG .25 X .38 X .25
16 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
17 86277500 70853 2 SCR, 1/4-20 X 5/8 CARR SS
18 86277130 70795 1 SCR, 5/16-18 X 1.00 CARRIAGE SS
19 86270830 57023 3 NUT, 5/16-18 HEX NYLOCK SS
20 86069440 140442 1 BRKT, LATCH
21 86008670 80606 4 COTTER, 3/8” RING
22 86271280 57163 2 NUT, 4-40 W/STAR WASHER
23 86007160 72157 1 SWITCH, 10A ROLLER MINI
24 86087520 73456 2 SPACER, L2020B PLUNGER SWITCH
25 86072460 14387 1 BRKT, MICRO SWITCH MOUNT
26 86276010 70580 2 SCR, 4-40 X 1.0 PPHMS
27 86223270 66482 1 PLUNGER, MICRO SWITCH
28 86270270 27721 2 CLIP, RETAINING 7/16
29 86007780 73576 1 SPRING, COMP .60D X 2.0L X .045W
30 86005630 57022 1 NUT, 3/8-16 HEX NYLOCK THIN SS
31 86222270 57276 2 NUT, PUSH FLAT RD .51 ID
32 86255650 81627 2 SPROCKET, #41 1/2” P 9T
33 86229000 09154 2 BEARING FLG .377ID X .502 OD X .500
34 86272520 66392 1 PIN, CLEVIS 3/8 X 2.75 PLTD
35 86276400 70642 1 SCR, 3/8-16 X 3 HHCS
36 86010680 87030 4 WASHER, 3/8 ID X 3/4 OD NYLON
37 86228910 09139 2 BEARING, FLANGED .377 ID X .502 OD
38 86290090 - 1 GUARD, CHAIN
*(2)
39 86232680 270114 1 CHAIN, #41, 1/2" PITCH X 34 P
40 86009400 81873 1 CHAIN, #41 1/2" P MASTER LINK
* SEE SERIAL NUMBER PAGE
