SCRUB DECK LIFT LINKAGE
86037880 CHARIOT EXTRACTOR 11/21/12
5-28
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86276070 70593 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
2 86272380 66217 1 PIN, CLEVIS 3/8 X .75 PLTD
3 86010770 87143 5 WASHER, 7/16 ID X 1 D X .08 FLT SS
4 86005630 57022 5 NUT, 3/8-16 HEX NYLOCK THIN SS
5 86271530 57216 4 NUT, 3/8-27 HEX NYLOCK
6 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
7 86009400 81873 1 CHAIN, #41 1/2” P MASTER LINK
8 86274660 70255 2 SCR, 3/8-16 X 1.5 HHCS GR5 PLT
9 86009050 81324 4 BEARING, 1/2 ID X 11/32L NYLON
10 86008460 80102 4 SPACER, .500 OD X .391 ID X .400
11 86093180 51415 1 LINKAGE ASM, DECK ARM
12 86224370 730335 4 SPACER, 1 OD X .391 ID X .500
13 86001320 140353 2 BALL JOINT ASSY, 3/8-24 LH
14 86005830 57263 2 NUT, 3/8-24 UNF LH
15 86223540 66483 2 ROD, SCRUB LIFT
16 86005800 57217 2 NUT, 3/8-24 HEX JAM
17 86008810 80697 2 BALL JOINT ASY, 3/8-24 RH
18 86087580 73606 2
SPACER, 1/2 OD X .058 W X .26 LG
CRS
19 86254980 730312 1 SPRING, EXT 1.312D X 8.00L X .225 W
20 86026210 68023 1 PIVOT ARM, W/BEARINGS
21 86002850 27343 2 CHAIN, #40, 1/2 P MASTER LINK
22 86232820 27981 1 CHAIN, #40, 1/2 PITCH X 4 ROLLER
23 86009100 81396 2 WASHER FIBERGLIDE 1/2” ID X 1” OD
24 86257830 66879 1 TUBE, .50 OD X .377 ID X 1.656
25 86275840 70550 1 SCR, 3/8-16 X 2.5 HHCS GR5 PLTD
26 86279260 87119 1 WASHER, .53 ID X 1.0 OD X .060 PLTD
27 86008680 80607 1 COTTER, 1/2” RING
28 86093560 68021 1 PIVOT ASSY DECK LIFT
29 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
30 86272320 66151 1 PIN, CLEVIS 1/2 X 2.75 LG
31 86270310 70760 2 EYEBOLT, 1/4-20 X 1.5 PLTD
