Windsor chariot iExtract CE24 User Manual

SOLUTION
86037880 CHARIOT EXTRACTOR 07/24/08
5-30
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86197940 40027 2 HOSEBARB, 3/8MPT X 1/2 OD 90D DL
2 86233150 20042 5 CLAMP, 3/8 HOSE (D-SLOT)
3 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS
4 86006100 65176 1 PUMP ASM, 36 V ACCESSORY
5 86010650 87018 6 WASHER, #10 X 6/16 OD
6 86070690 140724 1 BRKT, SOLUTION PUMP
7 86271820 57270 1 NUT, 5/16-18 CAPTIVE “J” PLTD
8 86274410 70195 4 SCR, 10-32 X 1.25 PPHMS SS
9 86240600 41526 1
HOSEBARB, 3/4 MPT X 1, HOSE 90 DEG
10 86198050 81923 1 TEE, 3/4 FPT
11 86240390 40075 1 HOSEBARB, 3/4 MPT X 1/2 90D
12 86247760 80960 1 NIPPLE, 3/4 CLOSE PVCE
13 86233300 20101 1 CLAMP, 1.25” WORM GEAR SS
14 86246090 51461 1 LANYARD, .093 X 6”, 1” LOOP-.26 EYE
15 86004310 39505 1 HOSE, 1.0 X 18.0 DRAIN
16 86248010 57312 1 NUT, 8-32 ACORN CAP, PLATED
17 86254320 730400 1 SPACER, .17 ID X .25 OD X 3/16LG
18 86073960 22104 1 CAP, 3/4” GHT W/ .17 HOLE
19 86252730 70887 1 SCR, 8-32 X 1/2 BHCS SST
20 86259450 87507 1 WASHER, 1.0 OD X .1 THK, SEAL
21 86226950 40109 1 1” HOSEBARB X 3/4” GHT NYLON
22 86233110 20018 1 CLAMP, 1.0” WORM GEAR
23 86274070 70086 2 SCR, 10-24 X 1/2 PPHMS
24 86233390 80887 2 CLAMP, 7/8 DIA “P” CUSHIONED
25 86270860 57028 2 NUT, 10-24 U-TYPE SPEED
26 86276780 70728 1 SCR, 5/16-18 X 3/4 HHCS SS
27 86279130 87083 1 WASHER, 5/16 SPLIT LOCK PLTD
28 86270830 57023 2 NUT, 5/16-18 HEX NYLOCK SS
29 86233410 81270 1 CLAMP, 3/4 DIA CUSHION .406 DIA
30 86277460 70847 1 SCR, 5/16-18 X 5/8 BSHCS SS
31 86264920 27049 2 CABLE TIE, 7” UL/CSA
32 86068780 140202 1 BRKT, STRAINER MNT
33 86282370 39735 1 HOSE, 1/2 ID WIRE BOUND X 58”
34 86001530 40039 1 HOSEBARB, 1/2 MPT X 1/2 HOSE 90
*(3)
35 86256120 730368 1 STRAINER, 1/2 FPT 100 MESH
*(3)
- 86252980 730369 - SCREEN, 100 MESH
36 86282360 39734 1 HOSE, 1/2 ID WIRE BOUND X 28”
37 86276070 70593 1 SCR, 5/16-18 X 3/4 CARRIAGE SS
38 86188210 11-800354 1 NIP, 1/2 X 3/8 HEX BR
*(3)
39 86225680 84201 1 VALVE, 3/8” FPT BALL
*(3)
40 86197420 31026 1 ELBOW, 3/8 NPT STREET
*(3)
41 86197540 40013 1 HOSEBARB, 3/8 MPT X 1/2 DL
*(3)
42 86281940 39540 1 HOSE, 1/2 ID WIRE BOUND X 40”
* SEE SERIAL NUMBER PAGE
