TANK
86037880 CHARIOT EXTRACTOR 11/20/12
5-34
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86221900 54198 1 MANDREL, BAG
2 86006470 67513 1 RETAINER, BACK BAG
3 86001510 140712 1 BAG, INNER TANK, EXT.
4 86003710 34447 1 FLAP, TANK DEBRIS
5 86006480 67514 1 RETAINER, MAIN BAG
6 86010630 87013 8 WASHER, 1/4 ID X 5/8 OD SS
7 86271940 57299 8 NUT, 1/4-20 ACORN SS
8 86246080 51368 1 LANYARD, 18.0 W/LOOP & EYE
9 86003350 28063 1 DOME, COVER, 10 X 13
10 86004010 35274 1 GASKET, DOME EDGE
11 86310180 - 1 PLATE, STRAINER BASKET
*(8)
12 86310190 - 1 BASKET, STRAINER, DOME
*(8)
13 86006860 70403 6 SCR, #10 1/2 PPHST TYPE B SS
14 86256100 730333 1 STRAINER, 3/4-MPT, 12 MESH
15 86276840 70744 8 SCR, 1/4-20 X 1 PFH BLK SS
16 86006760 70305 6 SCR, 5/16-18 X 3/4 HHCS GR5 PLTD
17 86279630 87212 6 WASHER, .344 ID X 1.13 OD X .09 TPLT
18 86064920 75473 1 TANK, DUAL VAC
19 86275800 70546 6 SCR, 8 X 3/4 PFHT/S BLK ZINC
20 86002620 260-64A 1 ACCESS COVER CLEAR 6” W/TRIM
21 86004000 35255 1 GASKET, TANK LID
22 86277560 70866 1 SCR, #6 X 1/2 SHT MTL SS
23 86033570 78934 1 TUBE ASM
24 86027800 34463 1 FLOAT, SINGLE SYSTEM
25 86227120 04095 1 ADAPTER, FLOAT 30 DEG
26 86199840 090-12A 1 FLOAT SCREEEN CAGE ASSY
27 86311740 - 1 HOSE, 2.0 X 37.0, DRAIN
**
- 86004430 39707 1 HOSE ASM, 2 X 37.0 DRAIN
ASM, HOSE &
CAP
28 86002380 20046 2 CLAMP, 2.25” WORM GEAR
29 86002390 20063 1 CLAMP, 1.75” WORM GEAR X .312
30 86257570 51407 1 TETHER, DRAIN HOSE, 1.5
31 86264950 27746 1 CABLE TIE, .19W X 11.5L BLK
*(4)
32 86309210 - 1 BAFFLE, FLOAT
*(4)
33 86371430 - - KIT, DOME BASKET
34 86328980 - 1 DRAIN CAP ASSEMBLY
* SEE SERIAL NUMBER PAGE.
**CALL MANUAFACTURER FOR SERIAL NUMBER
