VACUUM
86037880 CHARIOT EXTRACTOR 1/16/07
5-36
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86236540 34437 2 FOAM, POLY, 1/2 X 2 CURVED W/ADH
2 86238040 36243 4 GASKET, .25 T X .75 W X 24 L
3 86236530 34436 1 FOAM, POLYESTER, 1X3X18
4 86090140 270139 1 VAC CHANNEL COVER
5 86082110 62913 1 PLATE, CHAIN GUARD LT
6 86064740 270100 1 VAC CHANNEL COVER
7 86078650 36241 1 PLATE, CHAIN GUARD RT
8 86274070 70086 4 SCR, 10-24 X 1/2 PPHMS
9 86237890 35277 2 GASKET, VAC MOUNT
10 86237880 35276 2 GASKET, 5.7 VAC MOTOR
11 86005500 53809 2 VAC MOTOR 36VDC 3STG
12 86083100 66439 2 PLATE, HORIZ FLANGE RT
13 86083010 66428 2 PLATE, VAC SPACER
14 86270990 57090 8 NUT, 10-32 HEX NYLOCK SS
15 86270830 57023 6 NUT, 5/16-18 HEX NYLOCK SS
16 86083030 66430 2 PLATE, VAC MOTOR ADAPT
17 86270860 57028 4 NUT, 10-24 U-TYPE SPEED
