VACUUM SHOES
86037880 CHARIOT EXTRACTOR 06/29/09
5-38
REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO. FROM NOTES:
1 86006580 70085 10 SCR, 1/4-20 X 1/2 PPHMS SS
2 86075450 27246 1 COVER, VAC SHOE
3 86237910 35279 1 GASKET, VAC SHOE OUTER
4 86237920 35280 1 GASKET, 5.0 OD X 2.0 ID X .50T
5 86237930 35281 1 GASKET, VAC SHOE RIGHT
6 86237940 35282 1 GASKET, VAC SHOE CENTER
7 86237950 35283 1 GASKET, VAC SHOE WIPER
8 86295390 - 1 WIPER, VAC SHOE
*(5)
9 86275950 70568 4 SCR, 10-24 X 3/8 PPHMS SS
10 86293190 - 3 PIN, CLEVIS
*(9)
11 86310740 - 1 WIPER, W/GASKET
*(9)
12 86310750 - 1 ASSEMBLY, GASKETS, VAC SHOE
*(9)
13 86296410 - 1 PLATE, VACSHOE
*(9)
14 86302700 - 10 SCR, M6 X 16 PH, SS
*(9)
15 86296550 - 1 VACSHOE, 13 IN
*(9)
16 86296350 - 1 BUSHING, BRONZE, PM, 15.93 ID
* SEE SERIAL NUMBER PAGE
NOTE: Two vacuum shoe assemblies per machine.
