VACUUM SHOES LIFT
86037880 CHARIOT EXTRACTOR 11/15/08
5-40
REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO. FROM NOTES:
1 86276690 70715 8 SCR, 5/16-18 X 1.75 CARR SS
2 86278330 70641 1 SHOULDER BOLT, 3/8OD X 3/8L SS
3 86224370 730335 4 SPACER, 1 OD X .391 ID X .500
4 86259420 87232 4 WASHER, THRUST .51ID X 1 OD
5 86228840 09124 4 BEARING, FLANGED .314 ID X .502 OD
6 86010670 87029 4 WASHER, 5/16 FLAT SS
7 86080420 62416 1 PLATE, LIFT SLIDE
8 86270830 57023 13 NUT, 5/16-18 HEX NYLOCK SS
9 86080410 62415 4 PLATE, LIFT, WEIGHT
10 86093700 62424 1 PLATE, LIFT, ASSY
11 OPEN - - -
12 86219690 48080 2 KNOB, 1.5 OD X 5/16-18
13 86276650 70707 2 SCR, 5/16-18 X 1.5 BSHCS SS
14 86310730 - 2 VAC SHOE
*(9)
15 86276070 70593 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
16 86259400 87205 4 WASHER, THRUST 051 ID X 1 ODBRO
*(5)
17 86295380 - 2 PLATE, VAC SPACER
*(5)
* SEE SERIAL NUMBER PAGE
**CALL MANUFACTURER FOR SERIAL NUMBER
