VACUUM SHOE LIFT HANDLE
86037880 CHARIOT EXTRACTOR 08/14/07
5-42
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86238360 36215 1 GRIP, 3/16 X 1.0 ORANGE
2 86076610 38319 1 HANDLE, LIFT
3 86257120 72192 1 SWITCH, DPST SNAP ACTION
4 86008650 80604 1 COTTER, 1/4” RING
5 86279450 87161 2 WASHER, #6 FLAT SAE
6 86277490 70851 2 SCR, #6-32 X 1.38 PPHMS
7 86259420 87232 2 WASHER, THRUST .51D X 1 OD
8 86009560 82053 1 PIN, CLEVIS 1/4 X .63 PLTD
9 86270920 57049 2 NUT, 6-32 HEX NYLOCK SS
10 86007020 70673 1 SCR, 5/16-18 X 1.25 HHCS SS NP
11 86010670 87029 7 WASHER, 5/16 FLAT SS
12 86270830 57023 9 NUT, 5/16-18 HEX NYLOCK SS
13 86231150 09151 5 BUSHING FLANGE, .314 ID X .502 OD
14 86276760 70724 3 SCR, 5-16 X 1.25 BSHCS SS
15 86277460 70847 1 SCR, 5/16-18 X 5/8 BSHCS SS
16 86083440 66824 1 PLATE, PULLEY MOUNTING, CENTER
17 86223370 66464 4 PULLEY, PLASTIC 3.0 DIA
18 86231570 270105 1 CABLE, LIFT
19 86073600 66833 1 BRKT, PULLEY RETAINER, SINGLE
20 86083500 66832 1 PLATE, PULLEY RETAINER, CORNER
21 86083490 66831 1 PLATE, PULLEY MOUNT,CORNER
22 86066130 89501 1 ASM, HANDLE RETAINER
23 86254280 730331 1 SPACER, 1.00 OD X .32 ID X .375
24 86276070 70593 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
25 86091820 140807 1 BRKT, SIDE CHANNEL R
26 86295860 - 1 INSULATOR, SWITCH
*(6)
27 86274720 70264 1 SCR, 5/16-18 X 1.50 HHCS SS
* SEE SERIAL NUMBER PAGE
