Windsor chariot iExtract CE24 User Manual

VACUUM HOSES
86037880 CHARIOT EXTRACTOR 01/24/09
5-44
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86240320 39729 1 HOSE ASM, 1.5 BLK VAC X 36
2 86177050 03-000176 3 CLAMP, HOSE #20
3 86320330 - 2 HOSE ASM, 1.5 BLK VAC X 12
4 86003010 27759 1 CUFF, HOSE 1.5” BLK A 2161
5 86264950 27746 2 CABLE TIE, .19 W X 11.5L BLK
6 86277460 70847 2 SCR, 5/16-18 X 5/8 BSHCS SS
7 86270830 57023 2 5/16 HEX NYLOCK SS
8 86093200 54212 1 MANIFOLD
