TECHNICAL SPECIFICATIONS
CMD20 86038150 04/02/07
21
ITEM MEASURE
Electrical 115 V, 15 A, 60 HZ
Electric Propelling Motor (1) –1/4 hp DC (186 watts) with
variable speed forward.
Drive system Transaxle unit variable speed
Operating Speed: 0-100 ft/min
(30m/min)
Electric Vacuum Motor (1) – 3 stage, 1 hp 99 cfm
(2.80m³/min.)
Brush (1) 18” (45.8 cm)
Solution Pump 100 psi (6.9 bars), diaphragm style,
demand pump
Solution Capacity 20 gallons (75 ltr)
Recovery Capacity 20 gallons (75 ltr)
Brush Speed 1000 RPM
Vacuum Shoe 22” (56 cm) wide, cast urethane
floating and pivoting.
Wheels:
Front: (2) 4” dia. (10 cm) wheels by 2.5”
Rear: (2) 10” dia. (25 cm) wheels by 2”
Weight 215 lbs. (98kg)
Length 51” (130 cm)
Height 44” (111 cm)
Width 22” (56 cm)
Solution Spray 2 quick change jets
Power Cable 75’ (23m) (12 guage)
51''
44''
22''
SIDE VIEW FRONT VIEW
